Description
The RFS TPS4DE-350/2700 is a high-performance 4:1 tapper designed for unequal RF signal distribution in wireless communication systems. Supporting a broad frequency range of 350–2700 MHz, it features 7-16 DIN female connectors and operates with minimal RF insertion loss. The compact, lightweight design enhances installation flexibility, while its air dielectric structure and low intermodulation characteristics (IM3 < –150 dBc) ensure reliability and performance across cellular bands.
This tapper is ideal for use in indoor DAS networks and other RF signal distribution environments where dependable power handling (500W average) and consistent coupling flatness are essential.
Key Specifications
✅ Frequency Range: 350–960 MHz / 1710–2700 MHz
✅ Coupling Value: 7 dB (4:1 ratio)
✅ VSWR: ≤ 1.3
✅ Return Loss: ≥ 17.7 dB
✅ Insertion Loss (max): 1 dB
✅ Coupling Flatness (max): ±1.0 dB
✅ Power Handling: 500W average
✅ Impedance: 50 Ohm
✅ Connectors: 7-16 DIN Female
✅ Intermodulation (IM3): < –150 dBc (2x20W tones)
✅ Temperature Range: –10 to +55°C
✅ Ingress Protection: IP65
