Description
The RFS TP3DE-350/2700 is a rugged 3:1 RF tapper designed for high power signal distribution in DAS, in building wireless, cellular, and telecom RF systems. Supporting 350 to 960 MHz and 1710 to 2700 MHz frequency ranges, this tapper is built for professional RF distribution environments where stable signal performance and low PIM characteristics are important.
The unit features 7/16 DIN female connectors, an air dielectric design, compact construction, and reliable RF performance for space constrained installations. The product label identifies it as a 3:1 4.8 dB tapper, with 6.1 dB tap value and 1.3 dB insertion loss shown on the unit.
This tapper is suitable for indoor DAS networks, carrier grade wireless systems, telecom rooms, RF distribution paths, and in building wireless applications requiring dependable power handling, consistent RF performance, and low intermodulation.
Key Specifications
- Brand: RFS / Radio Frequency Systems
- Model: TP3DE-350/2700
- Product Type: RF Tapper / DAS Tapper
- Tap Ratio: 3:1
- Tapper Rating: 4.8 dB
- Tap Value: 6.1 dB shown on product label
- Insertion Loss: 1.3 dB shown on product label
- Frequency Range: 350 to 960 MHz / 1710 to 2700 MHz
- VSWR: ≤ 1.30
- Return Loss: ≥ 17.7 dB
- Intermodulation IM3: ≤ -150 dBc, 2 x 20 W tones
- Power Handling: 500 W average
- Impedance: 50 Ohm
- Connector Type: 7/16 DIN Female
- Ingress Protection: IP65
- Temperature Range: -10°C to +55°C
- Applications: Indoor DAS, in building wireless, cellular RF distribution, telecom systems, and RF signal distribution networks
- Condition: New / Open Box
