Optical Zonu A03-Z600-D55-AS-SW RF over Fiber Transceiver, 1550 nm DFB, Single-Mode, WDM

The Optical Zonu A03-Z600-D55-AS-SW is a high-performance RF over Fiber transceiver designed for transporting RF signals over single-mode fiber using a 1550 nm DFB laser. With a wide operating frequency range from 30 MHz to 3 GHz and integrated WDM functionality, it supports both unidirectional and bidirectional RF transport. This rugged, dust-tight module is ideal for applications like cellular backhaul, GPS distribution, antenna remoting, and in-building DAS deployments.

The A03-Z600-D55-AS-SW features a linear DFB laser, SC/APC connectors, and delivers superior SFDR, low phase noise, and optional manual gain control. It operates on +12 VDC and includes LED status indicators and DB9 alarm/monitoring interfaces for reliable system feedback.

Key Specifications

• Frequency Range: 30 MHz to 3 GHz

• Optical Wavelength: 1550 nm

• Connector Type: SC/APC

• Fiber Type: Single-mode (9/125 µm)

• Power Supply: +12 VDC

• Integrated WDM: Yes

• RF Interface: 50 Ω SMA

• Operating Temperature: -40°C to +75°C

• Applications: DAS, GPS, MMDS, Satcom, Cellular backhaul
