Description
The Microlab FY-10N is a low-PIM RF attenuator designed for wideband signal control in indoor wireless and telecom systems. Operating from 694 to 2700 MHz, this attenuator covers major commercial wireless bands and is suitable for DAS, in-building wireless, small cell, multiband antenna, leaky cable, and RF test applications.
Built with a multi-section stripline coupler, air dielectric design, and minimal solder joints, the FY-10N is engineered for stable attenuation, low VSWR, and strong passive intermodulation performance. This model provides 10.5 dB nominal attenuation and uses an N-Type male-to-female connector configuration for integration into RF signal paths.
Key Specifications
- Manufacturer: Microlab / RF Industries
- Model / MPN: FY-10N
- Product Type: Low-PIM RF Attenuator
- Attenuation: 10.5 dB ±1.0 dB
- Frequency Range: 694–2700 MHz
- Connector Type: N-Type Male to N-Type Female
- Power Rating: <10W max average
- VSWR: <1.25:1 from 694–2500 MHz; <1.35:1 from 2500–2700 MHz
- PIM / Intermodulation: <–110 dBm using +37 dBm × 2 tones
- Impedance: 50 Ohm nominal
- Housing / Finish: Passivated aluminum
- Operating Environment: Indoor, –20°C to +70°C
- RoHS Compliant: Yes
- Applications: DAS, LTE, 5G, small cell, in-building wireless, leaky cable, RF testing, and telecom infrastructure
- Condition: Used / Surplus
- Includes: Attenuator only; no cables, adapters, manuals, or accessories unless shown
