Description
The Microlab DN-64FE is a high-performance low-PIM RF tapper designed to unevenly split high-power cellular signals in wireless infrastructure systems. This model provides a 6:1 ratio / 8 dB tap value and operates across a broad 350 to 5930 MHz frequency range.
Equipped with 4.3-10 female connectors, the DN-64FE is suitable for DAS, in-building wireless, small cell, public safety, LTE, 5G, CBRS, multiband antenna, and telecom infrastructure applications. Its rugged IP67-rated housing, 500W average power rating, and -161 dBc PIM performance make it useful for demanding indoor and outdoor RF distribution systems.
This item is new / unused surplus. It may show minor handling marks or storage wear from warehouse inventory. Includes the DN-64FE tapper only; cables, adapters, test reports, mounting hardware, and additional accessories are not included unless shown.
Key Specifications
- Manufacturer: Microlab / RF Industries
- Model / MPN: DN-64FE
- Product Type: Low-PIM RF Tapper / Unequal Splitter
- Tap Ratio: 6:1
- Tap Value: 8 dB nominal / 8.5 dB branch split
- Main / Branch Split: Approx. -0.7 dB / -8.5 dB
- Frequency Range: 350–5930 MHz
- Connector Type: 4.3-10 Female, trimetal
- Average Power: 500W average
- Peak Power: 3 kW peak
- PIM Rating: -161 dBc, 2 tones at +43 dBm
- Dissipative Loss: <0.1 dB main line
- VSWR: 1.2:1 for 700–2500 MHz; 1.3:1 for 350–5930 MHz
- Impedance: 50 Ohm nominal
- Ingress Protection: IP67
- Housing / Finish: Passivated aluminum
- Operating Temperature: -40°C to +85°C
- RoHS Compliant: Yes
- Applications: DAS, LTE, 5G, CBRS, small cell, public safety, multiband antenna systems, and wireless infrastructure
- Condition: New / Unused Surplus
- Includes: Tapper only; no cables, adapters, mounting hardware, or accessories unless shown
